Carpanelli MRE系列電機IE3等級
Carpanelli MRE系列電機IE3等級特征:
緊湊的尺寸
可根據客戶需求定制
可適應多種電源電壓
可配置自制動裝置
可選速度傳感器 - 編碼器 - 解析器
低噪音水平
防護等級IP55,可根據要求 IP66
可選噴漆
可選溫度傳感器 PTC、PTO 或 PT100
Carpanelli MRE系列電機IE3等級2極系列
具體型號:
Carpanelli MRE80a2
Carpanelli MRE80b2
Carpanelli MRE100a2
Carpanelli MRE112a2
Carpanelli MRE132Sb2
Carpanelli MRE90Sa2
Carpanelli MRE90La2
Carpanelli MRE160Sa2
Carpanelli MRE80c2
Carpanelli MRE63a2
Carpanelli MRE71a2
Carpanelli MRE132Lb2
Carpanelli MRE160Sb2
Carpanelli MRE63b2
Carpanelli MRE71b2
Carpanelli MRE71c2
Carpanelli MRE132Sa2
Carpanelli MRE132La2
Carpanelli MRE112b2
Carpanelli MRE132Lc2
Carpanelli MRE160La2
Carpanelli MRE160Lb2
Carpanelli MRE100a2詳細參數舉例:
功率(KW)3
轉速2890
效率(%)87.1
標稱電流(A)5.96
標稱扭矩 NM 10
轉動慣量(kgm2*10-6)3520
啟動轉矩Cs/Cn 4.08
啟動電流As/An 8.25
Carpanelli MRE系列電機IE3等級4極系列
Carpanelli MRE63a4
Carpanelli MRE63b4
Carpanelli MRE71a4
Carpanelli MRE71b4
Carpanelli MRE80a4
Carpanelli MRE80b4
Carpanelli MRE80c4
Carpanelli MRE90Sa4
Carpanelli MRE90La4
Carpanelli MRE90Lb4
Carpanelli MRE100a4
Carpanelli MRE112a4
Carpanelli MRE112b4
Carpanelli MRE132La4
Carpanelli MRE132Lb4
Carpanelli MRE132Lc4
Carpanelli MRE160Sa4
Carpanelli MRE160La4
Carpanelli MRE63b4詳細參數舉例:
功率(KW)0.187
轉速1350
效率(%)67.4
標稱電流(A)0.6
標稱扭矩 NM 1.32
轉動慣量(kgm2*10-6)360
啟動轉矩Cs/Cn 2.81
啟動電流As/An 3.5
Carpanelli MRE系列電機IE3等級6極系列
Carpanelli MRE90La6
Carpanelli MRE90Lb6
Carpanelli MRE100a6
Carpanelli MRE100b6
Carpanelli MRE112a6
Carpanelli MRE112b6
Carpanelli MRE132Sa6
Carpanelli MRE132La6
Carpanelli MRE132Lb6
Carpanelli MRE160La6
Carpanelli MRE160Lb6
Carpanelli MRE160Lc6
Carpanelli MRE160Lc6詳細參數舉例:
功率(KW)11
轉速970
效率(%)90.3
標稱電流(A)24.8
標稱扭矩 NM 107.9
轉動慣量(kgm2*10-6)130430
啟動轉矩Cs/Cn 2.83
啟動電流As/An 7.37
