Conforti拉桿液壓缸CD-DK
符合ISO 6020/2的拉桿液壓缸，也用于磁性傳感器。
根據應用的條件和要求的性能，可在標準定義的每個安裝件中使用，并采用多種密封配置。
所有氣瓶在交付前都經過測試，符合ISO 10100的要求。
對于超過2000 mm的行程，我們建議評估HD-HK系列
產品特點
ISO
6020 /2 -DIN 24554內 孔
CD：從25到100
DK：從125到200
壓力
工作壓力：160 bar
最大：210bar
密封
高密封
低摩擦氟
橡膠
HFC-流體
選件
ROD
不銹鋼
硬化鋼
Nikrom
PROSSIMITY開關內置
板
傳感器
Conforti CD_SX_25_12_X_V_*_SJ 50_S___
Conforti CD_SX_25_18_A_Z_*_SJ 100_L_SF_SV_SR
Conforti CD_SX_32_14_B_K_*_SJ 150_H_ST_SZ_SH
Conforti CD_SX_32_18_E__*_SJ 200_G_SL_SK_
Conforti CD_SX_32_22_D__*_____
Conforti CD_SX_40_18_C__*_____
Conforti CD_SX_40_22_M__*_____
Conforti CD_SX_40_28_G__*_____
Conforti CD_SX_50_22_H__*_____
Conforti CD_SX_50_28_L__*_____
Conforti CD_SX_50_36_Q__*_____
Conforti CD_SX_63_28_R__*_____
Conforti CD_SX_63_36_S__*_____
Conforti CD_SX_63_45_T__*_____
Conforti CD_SX_80_36___*_____
Conforti CD_SX_80_45___*_____
Conforti CD_SX_80_56___*_____
Conforti CD_SX_100_45___*_____
Conforti CD_SX_100_56___*_____
Conforti CD_SX_100_70___*_____
Conforti CD_SX_125_56___*_____
Conforti CD_SX_125_70___*_____
Conforti CD_SX_125_90___*_____
Conforti CD_SX_160_70___*_____
Conforti CD_SX_160_90___*_____
Conforti CD_SX_160_110___*_____
Conforti CD_SX_200_90___*_____
Conforti CD_SX__110___*_____
Conforti CD_SX__140___*_____
co-ax同軸閥MK / FK 32 DR
特性
端口 螺紋 G 1 1/4 - G 1 1/2
法蘭 PN 16/40
功能 NC
壓力范圍 0-16 / 0-40 bar
A B max. 40 bar
B A max. 16 bar
A C max. 40 bar
C A max. 16 bar
KV值 A B 14,1 m³/h
A C 8,9 m³/h
介質 氣態 液態 高粘稠 凝膠狀 高污染
流向 見壓力范圍
開關周期 120 1/min
開關時間 打開 440 ms
關閉 250 ms
介質溫度 DC -20 °C — +100 °C
AC -20 °C — +100 °C
環境溫度 DC -20 °C — +80 °C
AC -20 °C — +80 °C
重量 MK 18,0 kg
FK 22,0 kg
標稱電壓 Un 24 V DC
Un 230 V 40-60 Hz AC
驅動 DC 直流電磁鐵
AC 內置式整流器的直流電磁鐵
絕緣等級 H 180 °C
防護等級 IP65
負載率 ED 100%
連接 按DIN EN175301-803標準的插頭, 形式A 4個位置X90°, 電線直徑 6-8 mm
閥門的設計是基于介質和工況的要求.這些因素可能導致設計、密封材料和特性與通用參數表上的規格有所不同.
