Blickle耐熱型單輪LI-POHI型號參數簡介



最小起訂貨量

  • 無限制

您可能還關注相似產品
  • 經營模式|生產廠家
  • 主營產品|主要產品包括: Blickle腳輪 Blickle導向輪 Blickle單輪 Blickle萬向腳輪 Blickle定向腳輪 Blickle輕型腳輪等
  • 公司榮譽|
供應產品分類
  • 暫無分類
本頁信息為blickle原廠生產的產品“Blickle耐熱型單輪LI-POHI型號參數簡介”產品信息,如您想了解更多關于“Blickle耐熱型單輪LI-POHI型號參數簡介”價格、型號、廠家的相關信息,請致電我們,或QQ在線交談。
品牌Blickle 有效期至長期有效 最后更新2020-05-07 13:45
瀏覽次數9

Blickle耐熱型單輪LI-POHI型號參數簡介

劉洋
QQ:2850590582  點擊這里給我發消息
手機:17744536447
電話:010-64714988-213
傳真:010-64714988668
郵件:-@handelsen.cn
劉洋郵箱:-@handelsen.cn電話:010-64714988-213

  Blickle耐熱型單輪LI-POHI型號參數簡介

  輪架:采用鋼壓制成型,萬向旋轉機構采用雙滾珠軸承,帶穩定的中心栓,通過對頂板配件進行專用設計而保護球。萬向旋轉機構采用比克力專用動載鉚接工藝,確保運行輕盈,使用壽命長,萬向旋轉寸動適用于高溫條件,附有耐高溫潤滑脂。螺栓輪軸。鍍鋅,藍色鈍化,不含六價鉻。

  單輪:輪胎/胎面: 采用優質耐沖擊耐高溫尼龍,滾動阻力和旋轉阻力很小,便于在光滑地面上行走,非常耐磨,適用于高壓滅菌器。

  軸承種類:滑動軸承

  單件重量:0.56kg

  萬向腳輪偏心距:38mm (F)

  總高度:102 mm (H)

  承載能力:150.00 kg

  輪寬:32mm (T2)

  輪徑:80mm (D)

  最低耐溫性:-25℃-250℃

  最高耐溫性:250℃

  胎面及輪胎硬度:85 Shore D

  頂板尺寸:100 x 85mm (A,B)

  螺栓孔徑:9 mm (d)

  螺栓孔間距:80×60mm (a,b)

  制造商 Blickle

  Blickle耐熱型單輪LI-POHI型號參數簡介

  Blickle型號示例:

  Blickle TPALRA-TPA,

  Blickle BRA-TPA,

  Blickle LKRA-TPA,

  Blickle BKRA-TPALPA-TPA,

  Blickle BKPA-TPALMDA-TPALDA-TPA

  Blickle VGALRA-VPA,

  Blickle BRA-VPA,

  Blickle LKRA-VPA,

  Blickle BKRA-VPA,

  Blickle BKRA-VGALKRA-VPA,

  Blickle BKRA-VPA,

  Blickle LKRA-VGA,

  Blickle BKRA-VGALPA-VPA,

  Blickle BPA-VPA,

  Blickle LKPA-VPA,

  Blickle BKPA-VPA,

  Blickle LKPA-VGA,

  Blickle BKPA-VGALMDA-VPALDA-VPA

  Blickle PATHLRA-PATH,

  Blickle BRA-PATH,

  Blickle LKRA-PATH,

  Blickle BKRA-PATHLPA-PATH,

  Blickle BPA-PATH,

  Blickle LKPA-PATH,

  Blickle BKPA-PATHLMDA-PATHLDA-PATH

  Blickle POALRA-POA,

  Blickle BRA-POA,

  Blickle LKRA-POA,

  Blickle BKRA-POALPA-POA,

  Blickle BPA-POA,

  Blickle LKPA-POA,

  Blickle BKPA-POALMDA-POALDA-POA

  Blickle LRA-VSTH,

  Blickle LKRA-VSTHLPA-VSTH,

  Blickle LKPA-VSTH

  Blickle LKDG-PUALKDB-PUA

  Blickle VELE-VE,

  Blickle B-VELER-VELEZ-VE

  Blickle L-V,

  Blickle B-V,

  Blickle BH-V

  Blickle LE-VPP,

  Blickle B-VPPLER-VPPLEZ-VPPL-VPP,

  Blickle B-VPP,

  Blickle BH-VPP

  Blickle LE-VGA,

  Blickle B-VGALER-VGA

  Blickle VELE-VE,

  Blickle B-VELER-VELEZ-VE

  Blickle VL-V,

  Blickle B-V,

  Blickle BH-V

  Blickle LE-VPP,

  Blickle B-VPPLER-VPPLEZ-VPPL-VPP,

  Blickle B-VPP,

  Blickle BH-VPP

  Blickle LE-TPA,

  Blickle B-TPALER-TPA

  Blickle VGALE-VGA,

  Blickle B-VGALER-VGA

  Blickle L-VW,

  Blickle B-VW,

  Blickle BH-VW

  Blickle L-VWPP,

  Blickle B-VWPP,

  Blickle BH-VWPP

  Blickle L-RD,

  Blickle B-RD,

  Blickle BH-RDLK-RD,

  Blickle BK-RD,

  Blickle BH-RD

  Blickle LE-POEV,

  Blickle B-POEVL-POEV,

  Blickle B-POEV,

  Blickle BH-POEVLK-POEV,

  Blickle BK-POEV,

  Blickle BH-POEVLKR-POEVLU-POEV,

  Blickle BH-POEVLH-POEV,

  Blickle BH-POEV

  Blickle L-ALEV,

  Blickle B-ALEV,

  Blickle BH-ALEVLK-ALEV,

  Blickle BK-ALEV,

  Blickle BH-ALEVLKR-ALEVLU-ALEV,

  Blickle BH-ALEVLH-ALEV,

  Blickle BH-ALEVLHZ-ALEVLO-ALEV,

  Blickle BO-ALEVLHD-SE,

  Blickle BOD-SE,

  Blickle LHD-ALEV,

  Blickle BOD-ALEV

  Blickle LK-SE,

  Blickle BK-SE,

  Blickle BH-SELU-SE,

  Blickle BH-SELH-SE,

  Blickle BH-SELO-SE,

  Blickle BO-SELS-SE,

  Blickle BS-SELSD-SE,

  Blickle BSD-SE

  Blickle LS-GEV,

  Blickle BS-GEV

  Blickle DS

  Blickle L-P,

  Blickle B-P

  Blickle LS-P,

  Blickle BS-P,

  Blickle LS-PS,

  Blickle BS-PS

  Blickle PK

  Blickle L-VLE,

  Blickle B-VLELS-VLE,

  Blickle BS-VLE

  Blickle L-VLE,

  Blickle B-VLELS-VLE,

  Blickle BS-VLE

  Blickle LE-PATH,

  Blickle B-PATHLER-PATHL-PATH,

  Blickle B-PATHLK-PATH,

  Blickle BK-PATH,

  Blickle BH-PATH

  Blickle L-POTH,

  Blickle B-POTH,

  Blickle BH-POTHLK-POTH,

  Blickle BK-POTH,

  Blickle BH-POTHLKR-POTHLU-POTH,

  Blickle BH-POTHLH-POTH,

  Blickle BH-POTHLH-POTH,

  Blickle BH-POTH

  Blickle L-ALST,

  Blickle B-ALST,

  Blickle BH-ALSTLK-ALST,

  Blickle BK-ALST,

  Blickle BH-ALSTLKR-ALSTLU-ALST,

  Blickle BH-ALSTLH-ALST,

  Blickle BH-ALSTLO-ALST,

  Blickle BO-ALST

  Blickle LU-GST,

  Blickle BH-GSTLH-GST,

  Blickle BH-GSTLO-GST,

  Blickle BO-GSTLS-GST,

  Blickle BS-GSTLSD-GST,

  Blickle BSD-GST

  Blickle LK-ALBS,

  Blickle BK-ALBS,

  Blickle BH-ALBSLKR-ALBSLU-ALBS,

  Blickle BH-ALBSLH-ALBS,

  Blickle BH-ALBSLS-ALBS,

  Blickle BS-ALBS

  Blickle L-ALTH,

  Blickle B-ALTH,

  Blickle BH-ALTHLK-ALTH,

  Blickle BK-ALTH,

  Blickle BH-ALTHLKR-ALTHLU-ALTH,

  Blickle BH-ALTHLH-ALTH,

  Blickle BH-ALTHLHZ-ALTHLO-ALTH,

  Blickle BO-ALTH

  Blickle LH-SETH,

  Blickle BH-SETHLO-SETH,

  Blickle BO-SETHLS-SETH,

  Blickle BS-SETH

  Blickle LU-GTH,

  Blickle BH-GTHLH-VSTH,

  Blickle BH-VSTH,

  Blickle LH-GTH,

  Blickle BH-GTHLO-GTH,

  Blickle BO-GTHLS-GTH,

  Blickle BS-GTHLOD-VSTH,

  Blickle BOD-VSTH,

  Blickle LOD-ALTH,

  Blickle BOD-ALTH,

  Blickle LOD-GTH,

  Blickle BOD-GTHLSD-VSTH,

  Blickle BSD-VSTH,

  Blickle LSD-GTH,

  Blickle BSD-GTH

  Blickle L-ALTH,

  Blickle B-ALTH,

  Blickle BH-ALTHLK-ALTH,

  Blickle BK-ALTH,

  Blickle BH-ALTHLKR-ALTHLU-ALTH,

  Blickle BH-ALTHLH-ALTH,

  Blickle BH-ALTHLHZ-ALTHLO-ALTH,

  Blickle BO-ALTH

  Blickle LH-SETH,

  Blickle BH-SETHLO-SETH,

  Blickle BO-SETHLS-SETH,

  Blickle BS-SETH

  Blickle LU-GTH,

  Blickle BH-GTHLH-VSTH,

  Blickle BH-VSTH,

  Blickle LH-GTH,

  Blickle BH-GTHLO-GTH,

  Blickle BO-GTHLS-GTH,

  Blickle BS-GTHLOD-VSTH,

  Blickle BOD-VSTH,

  Blickle LOD-ALTH,

  Blickle BOD-ALTH,

  Blickle LOD-GTH,

  Blickle BOD-GTHLSD-VSTH,

  Blickle BSD-VSTH,

  Blickle LSD-GTH,

  Blickle BSD-GTH

  Blickle LU-GB,

  Blickle BH-GBLH-VSB,

  Blickle BH-VSB,

  Blickle LH-GB,

  Blickle BH-GBLS-GB,

  Blickle BS-GBLSD-GB,

  Blickle BSD-GB

  Blickle LE-PO,

  Blickle B-POLER-POLEZ-POL-PO,

  Blickle B-POL-PO,

  Blickle B-PO,

  Blickle BH-POLK-PO,

  Blickle BH-PO LU-PO,

  Blickle BH-POLH-PO,

  Blickle BH-PO

  Blickle LE-POW,

  Blickle B-POWLER-POWL-POW,

  Blickle B-POWLK-POW,

  Blickle BK-POW

  Blickle LE-PPN,

  Blickle B-PPNLER-PPNL-PPN,

  Blickle B-PPN

  Blickle LK-SPO,

  Blickle BH-SPOLKR-SPOLU-SPO,

  Blickle BH-SPOLH-SPO,

  Blickle BH-SPOLHZ-SPOLT-SPO,

  Blickle BT-SPOLO-SPO,

  Blickle BO-SPOLS-SPO,

  Blickle BS-SPOLOD-SPO,

  Blickle BOD-SPO

  Blickle LH-GSPO,

  Blickle BH-GSPOLS-GSPO,

  Blickle BS-GSPOLSD-GSPO,

  Blickle BSD-GSPO

  Blickle L-G,

  Blickle B-G,

  Blickle BH-GLK-G,

  Blickle BK-G,

  Blickle BH-GLU-G,

  Blickle BH-GLH-G,

  Blickle BH-GLT-G,

  Blickle BT-GLO-G,

  Blickle BO-GLS-G,

  Blickle BS-G

  Blickle LH-SVS,

  Blickle BH-SVSLS-SVS,

  Blickle BS-SVS

  Blickle LH-SVS,

  Blickle BH-SVS

  Blickle BS-SPK

  Blickle SPKGSPO

  Blickle SPKVS

  Blickle DSPKGSPO

  Blickle DSPK

  Blickle FTH

  Blickle FSTH

  Blickle FPOB

  Blickle FPTH

  Blickle FPU

  Blickle FPO

  Blickle HTH

  Blickle HB

  Blickle HTHW

  Blickle HPO

  Blickle ALEV,

  Blickle ALST,

  Blickle ALTH,

  Blickle PO

  Blickle ALTH,

  Blickle GTH,

  Blickle VSTH

  Blickle GB

  Blickle RTH,

  Blickle RB

  Blickle GEVN

  Blickle GSTN

  Blickle GTHN

  Blickle GBN

  Blickle BSEV

  Blickle BEV

  Blickle BTH

  Blickle BB

  Blickle TB,

  Blickle TM

  Blickle FF

  Blickle WH

  Blickle SPKVSN

  Blickle GEVA

  Blickle GSTA

  Blickle GBA

  Blickle VLEA

  Blickle GEVN

  1953年 Blickle Raeder+Rollen GmbH u. Co. KG 成立于羅森菲爾德市

  1953 年,Wilhelm Sülzle 將其經營多年的五金廠拆分為三家獨立公司,分別贈予自己的兩個兒子和女婿 Heinrich Blickle。當時,新成立的比克力公司接手了鐵制手推車車輪的生產并由此發展出一眾品質優異的單輪、萬向腳輪和定向腳輪。正是得益于典型的施瓦本式美德,例如勤勞、質量為本和注重細節,不斷改進著產品。公司創始人 Heinrich Blickle 在 1961 年猝然離世,他的妻子 Elisabeth Blickle 女士接管了公司。

  如今,公司創始人的兒子 Reinhold Blickle 作為執行董事與他的妻子 Denise Blickle 女士以及 Walter Wager 共同掌管公司。在他們的領導下,比克力在過去數十年中成長為全球單輪和腳輪的頂尖制造商之一。在這一過程中,家族企業的傳統價值觀始終伴隨著進步不斷前行 - 這一企業價值理念也將由第三代繼承。
