主要名稱 電流：100 ... 600 A
一次電線直徑：大28 mm
一次剝皮1：30 x 10 mm
一次剝皮2：2x 20 x 10mm
寬度：61 mm
高度：75.5 mm
深度：58 mm
插入式電流互感器，其次級繞組可切換，初級電流范圍為200-100 A至600-300 A，次級電流1或5 A，額定功率2.5至15 VA，精度等級為1。
可以使用供貨范圍內的安裝腳或標準DIN 35mm導軌的專用夾子來固定變壓器。
輔助觸點可以用密封蓋固定。
MBS電流互感器ASK 31.4 2U簡介
一般性質
沒關系 連續熱電流I cth：1.0 x I N
沒關系 短期熱電流I th：60 x I N，1秒
過流編號：FS5
沒關系 動態電流I dynes：2.5 x I th
高 工作電壓U m：0.72 kV
絕緣測試電壓：3 kV，U eff，50 Hz，1分鐘。
標稱頻率：50赫茲
絕緣等級：E
防護等級：IP 20
工作溫度范圍：-5°C至+ 40°C
儲存溫度范圍：-25°C至+ 70°C
